ASUS PRIME B760-PLUS MOTHERBOARD(3y)
GAMING
SenseLK
Rs 51,150
In Stock
Available hours
Closed now
- Monday09:00 - 19:00
- Tuesday09:00 - 19:00
- Wednesday09:00 - 19:00
- Thursday09:00 - 19:00
- Friday09:00 - 19:00
- SaturdayToday09:00 - 19:00
- Sunday09:00 - 17:00
View more on,
Description
| Category | Details |
|---|---|
| Model | ASUS PRIME B760-PLUS |
| Form Factor | ATX (30.5 × 24.4 cm) |
| CPU Support | Intel LGA1700: 13th & 12th Gen Core, Pentium Gold, Celeron |
| Chipset | Intel B760 |
| Memory Slots | 4 × DDR5 DIMM, up to 192GB |
| Memory Speeds | DDR5 7200+(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000/5800/5600/5400/5200/5000/4800 |
| Memory Features | Dual-channel, XMP support, OptiMem II |
| Integrated Graphics Ports | 1 × DisplayPort 1.4 (4K@60Hz), 1 × HDMI 2.1 (4K@60Hz), 1 × VGA port |
| PCIe Expansion | 1 × PCIe 5.0 x16, 1 × PCIe 4.0 x16 (x4), 2 × PCIe 3.0 x1 |
| Storage | 3 × M.2 PCIe slots (M.2_1 PCIe 4.0 x4, M.2_2 PCIe 4.0 x4, M.2_3 PCIe 4.0 x2), 4 × SATA 6Gb/s |
| RAID Support | SATA RAID 0/1/5/10 via Intel Rapid Storage Technology |
| Ethernet | Realtek 2.5Gb Ethernet |
| Wireless | Optional via vertical M.2 Key E slot |
| Rear USB Ports | 1 × USB 3.2 Gen 2x2 Type-C, 2 × USB 3.2 Gen 2 Type-A, 1 × USB 3.2 Gen 1 Type-A, 2 × USB 2.0 |
| Front USB Ports | 1 × USB 3.2 Gen 1 Type-C connector, 1 × USB 3.2 Gen 1 header (2 ports), 2 × USB 2.0 headers (4 ports) |
| Audio | Realtek 7.1 HD Audio CODEC, premium capacitors, dedicated audio PCB layers |
| Audio Features | Jack detection, multi-streaming, front panel jack-retasking, 24-Bit/192kHz playback |
| Cooling Headers | 1 × CPU fan, 1 × AIO pump, 3 × chassis fan headers |
| Power Connectors | 24-pin ATX, 8-pin +12V EPS |
| RGB Headers | 1 × Aura RGB, 3 × addressable Gen 2 |
| Internal I/O Connectors | Clear CMOS, COM, front panel audio, S/PDIF, SPI TPM, system panel w/chassis intrude, Thunderbolt (USB4) header |
| ASUS Q-Design Features | Q-DIMM, Q-LED Core, Q-Slot |
| Thermal Solution | VRM heatsink, M.2 heatsink, PCH heatsink |
| Software Features | Armoury Crate, Aura Creator & Sync, Fan Xpert 2+, AI Suite 3, DIGI+ VRM, PC Cleaner, ASUS CPU-Z, Norton 360 Deluxe (trial), WinRAR |
| UEFI BIOS | 128Mb AMI UEFI, EZ Flash 3, CrashFree BIOS 3, EZ Mode |
| Manageability | WOL by PME, PXE |
| Accessories Included | 2 × SATA 6Gb/s cables, I/O Shield, M.2 rubber package, 2 × M.2 screws, User guide |
| Operating System Support | Windows 10 & 11 64-bit |
| Warranty | 3 Years |
Product Highlights
-
High-performance ATX motherboard with support for Intel 13th & 12th Gen CPUs.
-
PCIe 5.0 x16 slot and dual PCIe 4.0/3.0 slots for flexible GPU & expansion options.
-
Four DDR5 slots supporting up to 192GB for ultimate multitasking and gaming performance.
-
Three M.2 slots + 4 SATA ports for high-speed storage and RAID setups.
-
Realtek 2.5Gb Ethernet ensures fast, stable wired network connections.
-
Advanced cooling solutions including VRM, M.2 & PCH heatsinks, and hybrid fan headers.
-
Aura Sync RGB & addressable headers for fully customizable lighting.
-
Versatile USB connectivity, including front/rear Type-C and Thunderbolt/USB4 header support.
