DAHUA DH-XVR5108H-I3-8P 8CH 5M-N/1080P XVR(2y)
SECURITY SOLUTIONS
SenseLK
Rs 56,400
In Stock
Available hours
Closed now
- Monday09:00 - 19:00
- Tuesday09:00 - 19:00
- Wednesday09:00 - 19:00
- Thursday09:00 - 19:00
- Friday09:00 - 19:00
- SaturdayToday09:00 - 19:00
- Sunday09:00 - 17:00
View more on,
Description
| Category | Specification | Details |
|---|---|---|
| General | Model | DH‑XVR5108H‑I3‑8P |
| Channel Capacity | 8 analog channels plus support for IP extension (up to 12 channels total) | |
| Signal Format Support | HDCVI / AHD / TVI / CVBS analog + IP camera input support | |
| Form Factor / Storage Bays | Mini 1U chassis, supports 1 × SATA HDD (up to 16 TB) | |
| Recording & Resolution | Max Analog Resolution | Up to 5 MP (5M‑N) on analog inputs, also supports 4M‑N / 1080p / 720p |
| IP Camera Input / Incoming Bandwidth | Up to 12 IP channels, each up to 6 MP; incoming bandwidth up to 64 Mbps | |
| Compression & Streams | AI Coding + Smart H.265+ / H.265 / Smart H.264+ / H.264; dual‑stream support | |
| Smart / AI Features | SMD Plus (Human/Vehicle Filtering) | Up to 8 analog channels; by camera up to 12 channels |
| Perimeter Protection (Tripwire / Intrusion) | Up to 4 analog channels | |
| Face Recognition & Detection | Face detection: 2 channels analog; Face recognition: 1 channel analog; Face database up to 10,000 images | |
| Video Output & Display | Video Outputs | 1 × HDMI + 1 × VGA; HDMI up to 1920×1080 resolution |
| Screen Layout Options | When IP extension mode disabled: 1/4/8/9 display; when enabled: 1/4/8/9/16 display options | |
| Network & Interfacing | Network Interface | 1 × RJ‑45 (10/100 Mbps) |
| Protocols & Integration | HTTP, HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, FTP, DDNS, SNMP; ONVIF profiles supported | |
| Storage & Backup | HDD Interface | 1 × SATA up to 16 TB |
| Backup Methods | USB device backup & network backup supported | |
| Ports & External Interfaces | Audio In / Out | 1 × RCA audio input; 1 × RCA audio output; supports coaxial audio in some configurations |
| USB / RS‑485 / RS‑232 | 2 × USB 2.0 ports; 1 RS‑485 port; additional interfaces as per region | |
| Power & Environment | Power Supply | 53 V DC, approx 1.81 A typical for this model |
| Power Consumption | < 10 W (without HDD) | |
| Operating Temperature Range | –10 °C to +55 °C | |
| Storage Temperature Range | –20 °C to +60 °C | |
| Dimensions (W × D × H) | 325.0 mm × 257.1 mm × 55.0 mm | |
| Net Weight | ~1.60 kg | |
| Warranty | Manufacturer Warranty | 2‑year manufacturer warranty |
