DAHUA PFM800-4K PASSIVE VIDEO BALUN
SECURITY SOLUTIONS
SenseLK
Rs 2,000
In Stock
Available hours
Closed now
- Monday09:00 - 19:00
- Tuesday09:00 - 19:00
- Wednesday09:00 - 19:00
- Thursday09:00 - 19:00
- Friday09:00 - 19:00
- SaturdayToday09:00 - 19:00
- Sunday09:00 - 17:00
View more on,
Description
| Technical Specification | ||||
| Model | DH-PFM800-4K | |||
| Properties | ||||
| Transmission Signal | 1-CH | |||
| Network cable Type | UTP CAT5E/6 (material: CU) | |||
| Transmission Properties | HDCVI | 720P : max.400m
(1312.34ft) |
1080P : max.250m
(820.21ft) |
4M/6M/4K : max.200m
(656.17ft) |
| TVI | 720P : max.400m
(1312.34ft) |
1080P : max.250m
(820.21ft) |
4M/5M : max.200m
(656.17ft) |
|
| AHD | 720P : max.400m
(1312.34ft) |
1080P : max.250m
(820.21ft) |
4M/5M : max.200m
(656.17ft) |
|
| Video Transmission Properties | ||||
| Coaxial Video Connector | BNC-M | |||
| Connection Way | RJ45 | |||
| Compatible Format | HDCVI/TVI/AHD/CVBS | |||
| Resolution | 720P/1080P/4MP/5MP/4K | |||
| Protection | ||||
| ESD | 1a contact discharge electricity level 3 | |||
| 1b air discharge electricity level 3 | ||||
| Per: IEC61000-4-2 | ||||
| UTP Cable Connector | 2KV(different-mode), 4KV(common-mode) | |||
| Per: IEC61000-4-5 | ||||
| Impedance | ||||
| BNC Male Impedance | 75 ohms | |||
| UTP Cable Impedance | 100 ohms | |||
| Physical Properties | ||||
| Weight | 40g (0.09lb) (1 pair) | |||
| Dimension(LxWxH) | 173.8mmx19.5mmx21mm (6.84”x0.77“x0.83”) | |||
| Shell | ABS | |||
| Color | Black | |||
| Environmental | ||||
| Operating Temperature | -30℃~+70℃(-22℉~+158℉) | |||
| Operating Humidity | <95% RH | |||
| Storage Temperature | -40℃~+80℃(-40℉~+176℉) |
