DAHUA XVR5432L-I3 32CH PENTA-BRID 5M-N/1080P 4HDD(2y)
SECURITY SOLUTIONS
SenseLK
Rs 178,600
In Stock
Available hours
Closed now
- Monday09:00 - 19:00
- Tuesday09:00 - 19:00
- Wednesday09:00 - 19:00
- Thursday09:00 - 19:00
- Friday09:00 - 19:00
- SaturdayToday09:00 - 19:00
- Sunday09:00 - 17:00
View more on,
Description
| Category | Specification |
|---|---|
| Model | XVR5432L-I3 (32 Channel Penta-brid 5 MP-N / 1080P Value / 1.5U Rack-/Desktop Recorder with 4 SATA HDD Bays) |
| Series / Platform | WizSense Series – features AI-capabilities for detection & analytics |
| Video Input – Analog (BNC) | 32 BNC ports, supports auto-detect of HDCVI / AHD / TVI / CVBS formats |
| Video Input – IP Cameras | Supports up to 48 IP channels (when IP extension mode enabled) — base analog channels convertible to IP. Each IP channel may support up to 8 MP. |
| Maximum Resolution (Analog/Hybrid) | Analog input up to 5 MP-N (approx 5 MP) on supported channels; support for 4 MP, 1080p, 720p depending on format |
| Compression / Encoding | Smart H.265+ / H.265 dual-stream; Smart H.264+ / H.264 backwards compatibility; supports “AI Coding” on channels to reduce storage & bandwidth |
| AI & Smart Features | • SMD Plus (up to 32 analog channels) for human/vehicle filter • Perimeter Protection (up to 8 analog channels) with tripwire and intrusion detection • Face Recognition (up to 2 analog channels) • QuickPick 2.0 (2 channels for analog) for fast target retrieval |
| Video Output Ports | 2 × HDMI ports, 1 × VGA port HDMI1 may support 3840×2160 output; other outputs support full-HD and 1280×720/1024 resolutions |
| Display Split / Multi-Screen | Supported splits include 1 / 4 / 8 / 9 / 16 / 25 / 36 full-screen views depending on channel count and mode |
| Audio Interface | Analog Audio Input: 4-channel BNC (external) + 32-channel BNC (coaxial) Audio Output: 1-channel BNC Two-way talk supported on one channel |
| Alarm Interface | Alarm Input: 16 channels Alarm Output: 6 channels |
| Storage Interface | 4 × SATA ports for HDDs (each bay up to ~16 TB – varies with region/environment) 1 × eSATA port |
| USB / Serial / Control Ports | USB: 3 ports (1 front USB2.0, 2 rear USB3.0) RS-232: 1 port RS-485: 1 port Network Port: 1 × RJ-45 (10/100/1000 Mbps) |
| Network / Protocols | Network Port: 10/100/1000 Mbps Ethernet Supported protocols include HTTP, HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, FTP, DDNS, SNMP, P2P, Auto-Registration ONVIF Profile T/S/G, CGI, SDK supported for third-party camera integration |
| Power Supply / Consumption | Power Supply: 100-240 VAC, 50 Hz Power Consumption: < 22 W (without HDD) |
| Physical Dimensions & Weight | Dimensions: 440.0 mm (W) × 420.2 mm (D) × 76.0 mm (H) (approx 1.5U rack size) Net Weight: ~4.8 kg |
| Operating & Environmental Conditions | Operating Temperature: –10 °C to +55 °C Storage Temperature: –20 °C to +60 °C Humidity: 10%–90% RH, non-condensing |
| Certifications / Compliance | CE (LVD/EMC), FCC Part 15 Subpart B, EN 60950-1/IEC 60950-1, EN 61000-3-2/3-3, EN 55032, EN 55024, EN 50130 |
| Installation / Form Factor | Desktop or rack-mount friendly (1.5U size) with 4 HDD bays for extended storage capacity |
| Special / Additional Features | • Penta-brid technology: supports HDCVI, AHD, TVI, CVBS (analog) and IP camera inputs in one unit • AI Coding reduces required storage and bandwidth while preserving target detail • IoT & POS integration ready • Suitable for larger installs (32 channels analog + expanded IP) and future-proofing |
