DESKTOP MOTHERBOARD - ASUS TUF GAMING Z490-F (3y)
COMPUTER AND ACCESSORIES
SenseLK
Rs 88,900
In Stock
Available hours
Closed now
- Monday09:00 - 19:00
- Tuesday09:00 - 19:00
- Wednesday09:00 - 19:00
- Thursday09:00 - 19:00
- Friday09:00 - 19:00
- SaturdayToday09:00 - 19:00
- Sunday09:00 - 17:00
View more on,
Description
| Category | Details |
|---|---|
| Model Name | ASUS TUF Gaming Z490-F |
| Warranty | 3-Year Limited Warranty |
| Form Factor | ATX (305 × 244 mm) |
| CPU Socket | Intel LGA1200 – Supports 10th Gen Intel Core, Pentium Gold, and Celeron processors |
| Chipset | Intel Z490 |
| Memory Support | 4 × DDR4 DIMM slots, up to 128GB, dual-channel architecture |
| Memory Speed (OC / Supported) | Up to 4800 MHz (OC), supports 4600/4500/4400/4266/4133/4000/3866/3733/3600/3466/3333/3200/3000/2933/2800/2666/2400/2133 MHz |
| Integrated Graphics Outputs | 1 × HDMI 1.4b, 1 × DisplayPort 1.4 (dependent on CPU with integrated graphics) |
| Multi-GPU Support | NVIDIA 2-Way SLI and AMD 3-Way CrossFireX support |
| Expansion Slots | 2 × PCIe 3.0 x16 (x16 or x8/x8 modes), 1 × PCIe 3.0 x16 (x4 mode), 3 × PCIe 3.0 x1 |
| Storage Interfaces | 2 × M.2 sockets (one supports SATA & PCIe x4, one PCIe x4 only), 6 × SATA 6Gb/s ports, Intel Optane Memory Ready |
| Networking | Intel I225-V 2.5Gb Ethernet with ASUS LANGuard, M.2 E-Key slot for optional Wi-Fi module |
| Audio | SupremeFX S1220A 8-Channel HD Audio Codec, dual op-amps, premium capacitors, shielded audio PCB, optical S/PDIF out |
| USB (Rear I/O Ports) | 4 × USB 3.2 Gen 2 (3 × Type-A, 1 × Type-C), 2 × USB 3.2 Gen 1 Type-A, 2 × USB 2.0 |
| USB (Internal Headers) | 1 × USB 3.2 Gen 2 front panel header, 2 × USB 3.2 Gen 1, 2 × USB 2.0 headers |
| RGB & AURA Sync Support | 2 × Aura RGB headers, 2 × Addressable Gen 2 RGB headers, Aura Sync compatible |
| Cooling & Fan Headers | Multiple 4-pin fan headers, CPU fan, CPU OPT, AIO pump, chassis fans |
| Power Design | Robust VRM with alloy chokes and durable capacitors, ProCool socket, Digi+ VRM |
| DIY-Friendly Features | Pre-mounted I/O shield, Q-LEDs for diagnostics, BIOS FlashBack button, clear CMOS jumper |
| Software Utilities | AI Overclocking, AI Cooling, AI Networking, Armoury Crate, Fan Xpert 4 |
| Operating System Support | Windows 10 64-bit, Windows 11 64-bit (with BIOS update) |
| Accessories Included | User manual, I/O shield (pre-installed), M.2 screws, SATA cables, driver support |
