DOT MATRIX PRINTER - COLORSIT CP322+
OFFICE AUTOMATION
SenseLK
Rs 41,900
In Stock
Available hours
Closed now
- Monday09:00 - 19:00
- Tuesday09:00 - 19:00
- Wednesday09:00 - 19:00
- Thursday09:00 - 19:00
- Friday09:00 - 19:00
- SaturdayToday09:00 - 19:00
- Sunday09:00 - 17:00
View more on,
Description
| Normal speed (NLQ) |
High speed (DRAFT) |
Super high speed (SUPER-DRAFT) |
|
| 10 CPI | 56 CPS | 225 CPS | 300 CPS |
| 12 CPI | 67 CPS | 270 CPS | 337 CPS |
| Print head | Diameter of wire: 0.3 mm | ||
| Resolution | 240 x 144 dpi (Max.) | ||
| Character set | ASCII: 17 international character sets (U.S.A, FRANCE, GERMANY, U.K., DENMARK1, SWEDEN, ITALY, SPAIN 1, JAPAN, NORWAY, DENMARK2, SPAIN 2, LATIN AM, KOREA, LEGAL, HOLAND, TURKEY) |
||
| Code page | U.S.A, MULTI, PORTUGAL, CANADA, NORWAY, ICELAND, BRASCII, ABICOMP, ROMAN 8, ISO LTN 1, PC858, ISO LTN9, ARAB NLS, WIN 1256, TURKEY, WIN LAT1, CYRILLIC, RUSSIAN, THAI, VIETNAM |
||
| Fonts | ASCII: ROMAN, SANS SER Note: In high speed mode or super high mode, printer would automatically change the ASCII font to Draft when printing ASCII characters. |
||
| Bar code | EAN-13, EAN-8, Interleaved 2 of 5, Matrix 2 of 5, Industrial 2 of 5, Code 39, Code 128 B, Code 128 C, NW-7 |
||
| Character pitch | ASCII: 10 CPI, 12 CPI, 15 CPI, 17.1 CPI, proportional | ||
| Line spacing | 1/6 inch, programmable in 1/432 inch increments | ||
| Paper feed Speed | Normal mode | 3 inches per second (Continuous feed) | |
| 63 ms advance one line (1/6 inch) | |||
| Copy mode | 3 inches per second (Continuous feed) | ||
| 63 ms advance one line (1/6 inch) | |||
| Emulation | EPSON ESC/PK2, IBM2391 | ||
| Interface | This printer can be equipped with the following interfaces: Parallel interface: Centronics (IEEE1284 NIBBLE Mode) USB interface: USB 2.0 Full-Speed Serial interface: RS-232C Note: Please take the specific interface as standard. |
||
| Input Buffer | 132 KB | ||
| Ribbon | Model: JMR108 | ||
| Life: 3 million characters (draft mode) | |||
| Noise | ＜53 dB (A) (ISO7779 standard) | ||
| Control panel | Four buttons and four LED indicators. | ||
| Paper feed type | Cut sheet | Feed and eject from top |
Tractor paper Feed from rear and eject from top
| paper thickness adjustment |
Set through gap adjust lever | |
| Paper specification | Cut sheet | Width: 148 ~ 257 mm |
| Thickness: 0.065 ~ 0.14 mm | ||
| Weight: 52 ~ 90 g/m2 | ||
| Tractor paper | Width: 101.6 ~ 254 mm | |
| Total Thickness: 0.065 ~ 0.39 mm | ||
| Weight (Single ply): 52 ~ 82 g/m2 | ||
| Multiple paper (Every page): 40 ~ 64 g/m2 | ||
| Adhesive label | Width (Mount): 101.6 ~ 254 mm | |
| Smallest label: 63.5 × 23.8 mm | ||
| Thickness (Mount): 0.07 ~ 0.09 mm | ||
| Total thickness: 0.16 ~ 0.19 mm | ||
| Weight: 68 g/m2 | ||
| Max. paper thickness | 0.39 mm | |
| Copy | Original + 3 copies | |
| Compression | Support graph and character compression printing. | |
| Especial functions | Pin Break Compensation, Pin Rotation Replacement, Automatic Emulation Match, Online Parameter Setting |
|
| Physical dimensions | 366 (Width) × 275 (Depth) × 156 (Height) mm | |
| Weight | Approx. 4.3 Kg | |
| Environmental conditions |
Operating environment | Temperature: 5 ~ 35℃ |
| Humidity: 25 ~ 80 %RH (No condensation) | ||
| Storage environment | Temperature: -40 ~ 55℃ | |
| Humidity: ≤93 (40℃, No condensation) | ||
| Power requirements | Rated voltage: 220V(AC) | |
| Rated frequency range: 50Hz | ||
| Power consumption | Operating: 47 W; Standby: Approximately 3.6 W Note: Only when the product is unconnected with outer power supply, it can achieve zero energy consumption state. |
