Description
Product Specifications
| Specification Category | Details |
|---|---|
| Model | CP PLUS CP‑UVR‑0401E1 (4‑Channel DVR) |
| Series / Type | 1080P Lite / Cosmic / CORAL / HD Hybrid DVR |
| Processor & OS | Embedded processor with Embedded Linux |
| Video Signal Compatibility | Auto‑adaptive / hybrid inputs: supports HDCVI, AHD, HDTVI, CVBS (analog), plus IP camera input |
| IP Camera Input | 4 analog channels + 1 IP channel; IP channel(s) support up to 2 MP each |
| Video Compression | H.264 / H.264 dual‑stream; some variants support H.265 / “Instastream” / “AI‑coding” |
| Max Incoming Bandwidth | Approximately 20 Mbps (varies by model) |
| Video Output Interfaces | 1 × HDMI, 1 × VGA (simultaneous output) |
| Supported Output Resolutions | 1920×1080, 1280×1024, 1280×720 (other standard resolutions like D1, CIF) |
| Recording Modes / Frame Rates | Main stream: All channels support 1080N / 720P / 960H / D1 / CIF etc., at ~1‑25/30 fps depending on resolution; Sub‑stream: CIF (≈1‑15 fps) |
| Display Split Views | 1‑channel view, 4‑channel split view |
| Audio Input & Output | 1 RCA audio input; 1 RCA audio output |
| Motion Detection & Event Support | Yes – supports motion detection, video loss, tampering; multiple trigger events like snapshot, email/FTP alerts, etc. |
| Search & Playback Features | Time/date search; motion detection / alarm search; exact (to second) search; playback controls: play, pause, stop, rewind, fast/slow, next/prev file or camera, full screen, zoom etc. |
| Storage (HDD Support) | 1 × SATA HDD interface; supports up to 6 TB in most variants |
| Ports & Interfaces | 2 × USB 2.0 ports; RJ‑45 Ethernet (100 Mbps); RCA audio; reuse audio in/out (for two‑way talk via compatible setup) |
| User & Account Management | Supports up to 128 user accounts |
| Trigger / Alarm Outputs | Triggers for recording, PTZ, tour, alarm out, email/FTP/snapshot, buzzer etc. |
| Protocols & Network Features | HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, FTP, ONVIF, CGI, IP filter, P2P / IP Search depending on variant |
| Power Supply & Consumption | DC 12V / 1.5A; power consumption < ~10 W (without HDD) |
| Operating Conditions | Operating temperature: approx. ‑10°C to +45°C; humidity: 10‑90% RH (non‑condensing) |
| Physical Dimensions & Weight | Approx. 197 × 192 × 38 mm; weight ~0.55 kg (without HDD) |
Product Highlights
-
Flexible hybrid video system: supports both analog HD and IP cameras, enabling upgrades without replacing everything.
-
True Full‑HD recording across all 4 channels (1080N / 720P), so you get clear images even on all cameras at once.
-
Dual output (HDMI + VGA) lets you connect modern and older monitors simultaneously.
-
Generous storage potential with up to 6 TB HDD support—great for long‑duration recording.
-
Comprehensive alert & event features: motion detection zones, video loss, tampering, email/snapshot etc., giving proactive surveillance.
-
Easy remote monitoring: works with mobile apps (iCMOB, gCMOB) and desktop CMS / client software (KVMS / KVMS Pro).
-
Multiple user support (≈ 128 users), which is useful for businesses or locations requiring multi‑user access.
-
Compact and energy efficient: light power draw, modest size, suitable for small control rooms or home setups.
