DVR - HIVISON 8CH 4308

SECURITY SOLUTIONS

SenseLK

SenseLK

Rs 12,100

In Stock
Call

0706100100

Closed now
WhatsApp

+94706100100

Go to Product

https://www.sense.lk...

Available hours
Closed now
  • Monday09:00 - 19:00
  • Tuesday09:00 - 19:00
  • Wednesday09:00 - 19:00
  • Thursday09:00 - 19:00
  • Friday09:00 - 19:00
  • SaturdayToday09:00 - 19:00
  • Sunday09:00 - 17:00

View more on,

Description

Product Specifications

Specification Category Details
Model HIVISON / HiView 8‑Channel DVR (e.g. “4308” / HA‑46508)
Operating System / Firmware Embedded Linux OS
Video Inputs 8 analog channels via BNC; supports Hybrid inputs including AHD / TVI / CVI / CVBS / IPC (IP camera)
IP Camera Support Up to 8 IP channels (total input may combine analog + IP); IP channels support up to ~8MP each
Video Compression H.265 and H.264 formats (dual / standard streams)
Live Display Resolutions Analog live inputs: up to 4K (on supported analog formats) / 5MP / 4MP / 3MP / Full HD / 1080p / 720p etc.
Frame Rates (Analog / IP) - Analog: e.g. 4K@8fps, 5MP@20fps, 4MP/3MP/1080p/720p at up to ~25‑30fps depending on resolution
- IP: up to 8MP at ~25‑30fps where supported
Video Outputs HDMI (4K or higher resolution where supported), VGA, sometimes a CVBS / BNC spot output
Multi‑Screen Display Modes 1 / 4 / 6 / 8 / 9 / 13 / 16 split view options
Audio Input / Output 1 RCA audio input; 1 RCA audio output; audio possibly via coax in some analog channels; supports two‑way audio in compatible setups
Recording Modes Continuous, Scheduled/Timer, Motion detection, Smart/Alarm event based
Search & Playback Functions Search by date/time, event type (motion, alarm), tagged segments; playback controls: play / pause / stop / fast / rewind / forward etc.; multi‑channel simultaneous playback (often all 8)
Network & Remote Features RJ‑45 Ethernet (10/100 Mbps), protocols: TCP/IP, DHCP, PPPoE, DDNS, UPnP, HTTP/HTTPS; remote access via CMS software and mobile apps on iOS/Android; ONVIF compatibility in many cases
Storage / HDD Support 1 SATA hard drive bay (single HDD), capacity up to 10‑TB (depending on model)
Backup Options USB backup, network backup, local external HDDs or USB sticks
Bandwidth / Streams Incoming / outgoing bandwidth in the tens of Mbps (e.g. ~32‑80 Mbps depending on resolution / number of active IP channels)
Ports & Interfaces USB 2.0 ports x2, RS‑485 for PTZ / remote control / keyboard, standard BNCs, Ethernet port, audio I/O
Power Requirements ~12 V DC adaptor; consumption ~ ≤15 W (without HDD) depending on model
Physical Dimensions Approx. 255 × 234 × 42 mm (W × D × H) in typical versions
Operating Environment Operating temperature approx −10 °C to +50 °C; Humidity ~10‑90% non‑condensing

Product Highlights

  • Supports 8 analog channels + up to 8 IP channels, giving flexibility for mixed camera setups and future upgrades.

  • Delivers high‑quality recordings with support up to 5‑8 MP on IP, and high‑resolution analog inputs (4K / 5MP etc.), subject to model.

  • Efficient compression (H.265 + H.264) reduces storage and bandwidth demands without compromising image clarity.

  • Multiple recording modes (continuous, motion, scheduled) and advanced event triggers (motion, smart events), helping you catch important moments.

  • Rich search and playback tools make reviewing footage easy — fast access to events, time/date, and simultaneous playback of all channels.

  • Flexible output options (HDMI, VGA, sometimes spot output) for various monitor setups.

  • Remote access through apps and CMS, plus network features like DDNS / DHCP / PPPoE etc., so you can monitor from anywhere.

  • Large storage support (up to 10 TB) and easy backup options ensure important video is safe and retrievable.
