FIBER NETWORK MODULE - DAHUA PFT3950 MULTI MODE
SenseLK
Rs 13,600
- Monday09:00 - 19:00
- Tuesday09:00 - 19:00
- Wednesday09:00 - 19:00
- Thursday09:00 - 19:00
- Friday09:00 - 19:00
- SaturdayToday09:00 - 19:00
- Sunday09:00 - 17:00
View more on,
Description
Product Specifications
| Specification Category | Detail |
|---|---|
| Brand | Dahua |
| Model | PFT3950 Multi‑Mode SFP Fiber Module |
| Module Type | SFP (Small Form‑factor Pluggable) optical transceiver module |
| Fiber Type | Multi‑mode fiber |
| Connector Type | LC duplex connector (Tx & Rx) |
| Wavelength (Tx / Rx) | 850 nm (both transmit and receive) |
| Max Data Rate / Transfer Speed | 1.25 Gbps |
| Transmission / Network Protocol | IEEE 802.3z / 1000Base‑FX / Compliant with SFP / MSA standards |
| Maximum Transmission Distance | Up to 500 meters (≈ 1,640 ft) over multimode fiber |
| Power Supply | 3.3 V DC |
| Operating Temperature Range | ‑40 °C to +85 °C |
| Housing / Form Factor | Hot‑swappable, standard SFP module |
| Light Source Type | FP (Fabry‑Perot) laser |
| Number of Fibers Used | 2 (one for transmit, one for receive) |
| Optical Connector Gender / Polarity | LC / duplex; Tx and Rx fibers need correct alignment |
| Dimensions (Module) | Approx. 60 × 15 × 10 mm |
| Weight | Approx. 0.02 kg |
| Certifications & Compliance | Class 1 Laser Product; IEC/EN safety standards; compatible with standard fiber networking norms |
Product Highlights
-
High‑speed 1.25 Gbps multimode fiber module perfect for linking switches, routers, or network devices over short distances within buildings.
-
LC duplex connectors ensure reliable bi‑directional optical communication, with separate fibers for transmit and receive.
-
Wide operating temperature range (‑40 °C to +85 °C) makes it suitable for challenging environments, indoor or outdoor enclosures.
-
Hot‑swappable SFP form factor allows easy installation or replacement without shutting down network equipment.
-
Up to 500 meters transmission distance using multimode fiber, ideal for large premises, campuses, or extended CCTV networks.
-
Low power consumption thanks to 3.3 V DC requirement, helping minimize energy usage in large deployments.
-
Fabry‑Perot (FP) laser source ensures cost‑effective optical performance for multimode fiber systems.
-
Robust build and standard compliance give peace of mind for safety, compatibility, and long‑term reliability.
