RUIJIE REYEE RG-NBS3200-24GT4XS-P 24 PORT GIGABIT L2 CLOUD MANAGED PoE SWITCH(3y)
SenseLK
Rs 260,900
- Monday09:00 - 19:00
- Tuesday09:00 - 19:00
- Wednesday09:00 - 19:00
- Thursday09:00 - 19:00
- Friday09:00 - 19:00
- SaturdayToday09:00 - 19:00
- Sunday09:00 - 17:00
View more on,
Description
| Category | Details |
|---|---|
| Brand | Ruijie Reyee |
| Model | RG-NBS3200-24GT4XS-P |
| Device Type | 24-Port Gigabit L2 Cloud-Managed PoE+ Switch |
| Port Configuration | 24 × 10/100/1000 Mbps RJ45 PoE+ ports |
| Uplink Ports | 4 × 10G SFP+ uplinks |
| PoE Standards | IEEE 802.3af/at |
| Total PoE Budget | 370W |
| Max Power per Port | Up to 30W |
| Switching Capacity | 128 Gbps |
| Forwarding Rate | Up to 95 Mpps |
| MAC Address Table | Supports up to 16,000 MAC entries |
| VLAN Support | Up to 4,094 VLANs |
| Buffer Memory | 12 Mbit packet buffer |
| Layer 2 Features | STP/RSTP, link aggregation, IGMP snooping v1/v2/v3, jumbo frames, BPDU guard, port mirroring, broadcast storm control |
| Security Features | ACLs, DHCP snooping, ARP inspection, IP source guard, IP-MAC binding, PoE overload protection |
| Cloud Management | Full cloud support via Ruijie Cloud & Reyee App |
| AI Features | Auto-detection of IP cameras/APs, smart port configuration, intelligent power allocation |
| Surge Protection | 6kV surge protection on all ports |
| Reliability | MTBF > 200,000 hours |
| Energy Efficiency | < 432W max consumption under full load |
| Cooling System | Adaptive cooling for stable operation |
| Dimensions | 440 × 357.6 × 43.6 mm (1U rack-mount size) |
| Weight | Approx. 4.75 kg (with packaging) |
| Mounting Options | Standard 1U rack-mountable |
| Use Case Scenarios | SMB networks, surveillance deployments, enterprise Wi-Fi, campus networks |
| Management Type | Cloud-managed L2 switch with zero-touch provisioning |
| Warranty | 3-year warranty |
Product Highlights
-
Enterprise-Grade PoE Delivery: 24 PoE+ ports with a 370W power budget make it ideal for powering IP cameras, APs, and VoIP phones.
-
High-Speed 10G Uplinks: Four 10G SFP+ uplink ports ensure smooth integration with core switches and high-bandwidth applications.
-
Cloud-Managed Simplicity: Full cloud access through Ruijie Cloud and Reyee App allows zero-touch provisioning, remote monitoring, firmware upgrades, and AI-assisted troubleshooting.
-
Advanced L2 Switching: VLANs, IGMP snooping, link aggregation, and STP/RSTP provide flexible network segmentation and enhanced traffic optimization.
-
Comprehensive Security: Protects the network with ACL filtering, DHCP snooping, IP source guard, ARP inspection, and IP-MAC binding.
-
Smart Surveillance Optimization: Auto-detection and auto-configuration for IP cameras ensure fast setup and reliable video streaming.
-
Built for Longevity: Industrial-grade build quality, 6kV surge protection, and high MTBF ensure long-term network stability.
-
Rack-Mount Ready Design: Standard 1U metal chassis fits easily into server racks for professional installations.
