Cooler Master GX II 850W 80 Plus Gold Power Supply

Cooler Master GX II 850W 80 Plus Gold Power Supply





* ATX 3.0 support & a durable 12VHPWR cable

* 80 Plus Gold certified efficiency

* Silent fan performance with a zero-RPM mode

* Separated thermal technologies

* Fully modular cabling





Specifications

Model

850: MPX-8503-AFAG-2BUK



ATX Version

ATX 12V Ver. 3.0



PFC

Active PFC



Input Voltage

100-240V



Input Current

10-5A



Input Frequency

50-60Hz



Dimensions (L x W x H)

160 x 150 x 86 mm



Fan Size

120mm



Fan Bearing

HDB



Fan Speed

2500 RPM



Efficiency

≥90% @ Typical Load



80 PLUS Rating

80 PLUS Gold



ErP 2014 Lot 3

Yes



Operating Temperature

0-40°C



Power Good Signal

100 - 150 ms



Hold Up Time

≥16ms at 80% Load



MTBF

>100,000 Hours



Protections

OPP/ OVP/ OTP/ OCP/ SCP/ UVP/ Surge & Inrush Protection



Regulatory

cTUVus, TUV, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC (Based on region's requests.)



ATX 24 Pin Connectors

1



EPS 4+4 Pin Connectors

1



EPS 8 Pin Connector

1



SATA Connectors

6



Peripheral 4 Pin Connectors

2



PCI-e 6+2 Pin Connectors

4



12VHPWR Connector

1



Series

GX Series



80 Plus

Gold



Modular

Fully Modular



Category

Above 750W



Form Factor

ATX



Watts

850W
